Products Description
Product performance
1、 Basic parameters
project parameters
Model PFRL101C
Rated load (range) 2.0 kN (approximately 204 kgf)
Order number 3BSE002964R002
Measure radial force in the direction perpendicular to the installation axis
Output signal analog mV/V (typical sensitivity: about 2 mV/V)
Recommended power incentive: 5-10 V DC (standard is 10 V)
Protection level IP65 (dustproof, waterproof), suitable for industrial environments
Material: high-strength alloy steel, surface nickel plating or anti-corrosion treatment
Working temperature range -10 ° C to+70 ° C (optional wide temperature version)
2、 Precision performance characteristics
1. High precision and linearity
Nonlinear error: ≤± 0.1% F.S. (full scale)
Repetitive error: ≤± 0.05% F.S
Lag error: ≤± 0.1% F.S
The overall comprehensive accuracy can reach ± 0.15% F.S., meeting the high requirements of tension control scenarios
2. Excellent dynamic response
High natural frequency (>1 kHz), suitable for high-speed operating equipment (such as film, paper, metal foil production lines)
Fast response time, able to capture tension fluctuations in real time
3. Temperature compensation design
Built in full bridge strain gauges+temperature compensation circuit
Small temperature drift:
Zero temperature drift: ≤± 0.02% F.S./° C
Sensitivity temperature drift: ≤± 0.03% F.S./° C
4. Anti interference and stability
Fully sealed structure, moisture-proof, oil proof, and vibration resistant
Long term stability is good (annual drift<± 0.1% F.S.)
3、 Mechanical and installation characteristics
