Product performance

Measurement and Control Precision

Overall accuracy: ±0.1% FS (typical)/maximum ±0.2% FS, repeatability ±0.1% FS, nonlinearity ±0.1% FS, ensuring a tension closed-loop steady-state error ≤0.2%.

Resolution: 0.01 kN (10 N), corresponding to 1/1,000 resolution within a 10,000 N range, meeting high-resolution closed-loop requirements.

Annual drift: ≤0.2%/year, reducing frequent calibration and improving long-term control consistency.

Dynamic and Response Characteristics

Step response time: ≤10 ms (10%→90%), capable of supporting a tension closed-loop bandwidth of 100 Hz.

Built-in digital filtering algorithm to suppress mechanical vibrations and high-frequency noise, preventing actuator misoperation.

Fatigue life: >1×10⁷ cycles, suitable for continuous high-speed production lines.

Output and Communication Interface

Standard 4–20 mA / 0–10 V dual-mode analog output, compatible with PLC and DCS analog modules; current output load capability ≤500 Ω, voltage output drive ≥2 kΩ.

Optional fieldbuses such as HART, Profibus-DP, and Modbus RTU (via external PFEA series amplifiers or adapter modules) enable remote setpoint adjustment, gain tuning, and real-time diagnostics.

Ultra-low power consumption: ≤3.6 W, suitable for two-wire loop or battery/solar power supply
