Products Description
Product performance
The "control box" for PFCL201CE 10KN 3BSX105983-100 is not an independent PID controller but refers to the native amplification-interface module built-in/supplied with the sensor (also known as the "control box" or "junction box"). It directly converts the millivolt-level signal from the piezoresistive sensor into a standard analog output and provides hot-swapping, bus expansion, and diagnostic interfaces. Key performance features include:
Measurement and Output Performance
Rated range: 0–10 kN, comprehensive accuracy ±0.1% FS, repeatability ±0.05% FS, temperature drift ≤0.02%/10 K.
Analog output: Dual-mode 4–20 mA (load ≤550 Ω) and 0–10 V (load ≥2 kΩ), powered by 24 VDC with a power consumption of ≤3 VA.
Response time: ≤10 ms (-3 dB bandwidth DC–2 kHz), compatible with high-speed reels exceeding 1,000 m/min.
Communication and Expansion
The side of the box body is equipped with pre-installed slots for Profibus-DP, Profinet, Modbus-TCP, etc. By adding the corresponding sub-cards, remote setpoint adjustment, gain auto-tuning, and real-time tension/status register reading can be achieved.
Support for hot-swapping: Sensors or modules can be replaced or upgraded without interrupting the system, minimizing downtime.
