Products Description
Product performance
PFCL201C 3BSE023409R20 is not an independent "controller", but an order number for the "control cabinet/interface cabinet" in ABB Millmate strip tension measurement system. It corresponds to a complete cabinet (commonly known as Millmate 400 Control Cabinet) that connects 2-4 PFCL201C series piezoelectric sensors to the system and completes signal conditioning, amplification, communication, and power distribution. Its core performance can be summarized as follows:
Signal processing performance
24-bit Δ-Σ ADC， Sampling at 10 kHz per channel, with a bandwidth of DC-2 kHz, capable of tracking high-speed strips up to 1000 m min ⁻¹ level.
Comprehensive measurement chain accuracy ± 0.1% FS, resolution 1/1000, repeatability ± 0.05% FS, temperature drift ≤ 0.02%/10K, ensuring tension closed-loop steady-state error ≤ 0.3%.
Output and Communication Interface
Standard configuration: 4-channel isolated 4-20 mA/0-10 V switchable output, maximum load of 550 Ω (current)/2 k Ω (voltage); Two 16 bit analog inputs are used for roll diameter or speed feedforward.
Digital terminals: 8 DI (24 VDC) (for start, direction, alarm reset, etc.), 8 DO (relay 230 VAC/2 A) for holding brake, quick stop, tension/relaxation indication.
Communication slot: TCP/IP 100M, RS-232 maintenance port; Optional Profibus DP, Profinet, EtherNet/IP, Modbus TCP, can be seamlessly integrated with ABB AC500, 800xA or third-party PLC/DCS.
Control and computation functions
Built in 32-bit ARM Cortex-M7 main MCU, 128 MB SDRAM, supports multi-stage linearization, temperature compensation, roll diameter compensation, and mechanical inertia compensation.
Provide threshold comparator, peak holding, band breakage detection, and tension fluctuation (RMS) statistics; Trend charts and historical data can be viewed in real-time through a web server.
