Products Description
Product performance
After connecting 2-4 PFCL201C piezoelectric sensors to the PFCL201C 3BSE023409R20 control box (i.e. the amplification/interface box or Millmate 400 cabinet that matches the sensors), it completes 24 bit high-speed sampling, multi communication protocol conversion, and local I/O. The performance points are as follows:
signal processing
24-bit Δ-Σ ADC， Sampling at 10 kHz per channel, bandwidth of DC-2 kHz, step response ≤ 1 ms, meeting the requirement of 1000 m min ⁻¹ level high-speed coil.
Comprehensive measurement chain accuracy ± 0.5% FS, nonlinearity ± 0.2% FS, repeatability ± 0.1% FS, temperature drift ≤ 0.02%/10K, long-term drift<0.2%/year.
Output and Communication
Standard configuration includes 4 isolated 4-20 mA/0-10 V switchable outputs, with a load of 550 Ω (current)/2 k Ω (voltage).
Digital terminal: 8 DI+8 DO (relay 2 A), used for holding brake, quick stop, and direction signal.
Slot based communication: optional Profibus DP, Profinet, EtherNet/IP, Modbus TCP, plug and play with ABB AC500 or third-party PLC/DCS.
